Yokogawa DL850E Scopecorder Repair and Calibration

Yokogawa logo

$245.00 evaluation fee

🛡️ 90-Day Warranty ✓ Fee Credited to Repair ⚡ No Forms Needed

Component-level Yokogawa DL850E repair backed by a 90-day warranty. We restore full performance for trigger modes and protocol decode functions.

đź“‹ How It Works

  1. Submit Request – Pay evaluation fee & provide equipment details
  2. Ship to Us – Send your equipment to our Oregon facility
  3. We Evaluate – Detailed diagnosis & repair estimate
  4. Fee Credited – Your evaluation fee applies to repair cost
  5. We Repair – Professional repair with 90-day warranty
  • đź”§ Fast Turnaround: Most repairs are completed within 1–3 business days.
  • 📏 Precision Calibration: NIST-traceable calibrations included for most repairs.
  • 🛡️ Warranty: 90-day warranty on all repairs.
  • 📝 Transparency: Detailed evaluation and repair estimate before work begins.
âś“ Evaluation Fee Credited Toward Repair

This evaluation fee is applied as credit toward your final repair cost. After we evaluate your equipment, you'll receive a detailed estimate before any repair work begins.

Description

Yokogawa DL850E ScopeCorder Repair and Calibration

The Yokogawa DL850E is a ScopeCorder — a hybrid instrument combining the high-speed capture of an oscilloscope with the long, multi-channel recording of a data recorder, using plug-in input modules to capture mixed electrical and physical signals for power, automotive, and mechatronics testing. As a modular capture instrument, its faults concentrate in the input modules/channels, the acquisition/memory system, the trigger, and the display.

June Company repairs and calibrates the Yokogawa DL850E for power, automotive, and mechatronics test teams.

Common Yokogawa DL850E problems we fix

  • Trigger-mode faults — triggering not working across its modes, repaired and recalibrated.
  • Protocol-decode / analysis faults — the serial-decode or analysis function not working, restored.
  • Input-module / channel faults — a dead or inaccurate channel/module, repaired.
  • Memory / acquisition faults — lost or corrupt captures, restored.
  • Display or interface faults.

FAQs

My DL850E trigger or decode isn’t working — fixable? Yes. Trigger, decode, and input faults are repairable, then channels are recalibrated so capture is reliable and accurate, with a NIST-traceable certificate.

Are the input modules verified? Yes — each installed module is checked against our standards.

Every repair includes NIST-traceable calibration and a 90-day parts-and-labor warranty. Email us or submit a service request.
