Hioki PW3198 Power Quality Analyzer Repair and Calibration

$245.00

🛡️ 90-Day Warranty ✓ Fee Credited to Repair ⚡ No Forms Needed

Expert Hioki PW3198 repair and calibration with documented test results. Trusted by power electronics engineers, motor drive designers, inverter manufacturers, and energy efficiency test labs nationwide.

Helpful Resources

📋 How It Works

Submit Request – Pay evaluation fee & provide equipment details
Ship to Us – Send your equipment to our Oregon facility
We Evaluate – Detailed diagnosis & repair estimate
Fee Credited – Your evaluation fee applies to repair cost
We Repair – Professional repair with 90-day warranty

🔧 Fast Turnaround: Most repairs are completed within 1–3 business days.
📏 Precision Calibration: NIST-traceable calibrations included for most repairs.
🛡️ Warranty: 90-day warranty on all repairs.
📝 Transparency: Detailed evaluation and repair estimate before work begins.

✓ Evaluation Fee Credited Toward Repair

This evaluation fee is applied as credit toward your final repair cost. After we evaluate your equipment, you'll receive a detailed estimate before any repair work begins.

Description

Hioki PW3198 Power Quality Analyzer Repair and Calibration

The Hioki PW3198 Power Quality Analyzer is a power analyzer – it does not simply measure voltage and current but computes real power, power factor, harmonics and efficiency from them, at high sample rates and across multiple phases. The computed values are what gets reported, and they depend on phase accuracy between channels.

June Company repairs and calibrates the Hioki PW3198 Power Quality Analyzer for power electronics engineers, motor and drive test teams, energy auditors, and efficiency laboratories. Every instrument is repaired at component level and verified against reference standards before it ships back, with the measured results documented.

Common Hioki PW3198 Power Quality Analyzer problems we fix

Phase accuracy between channels drifted – the fault that corrupts every power and power-factor figure while voltage and current both read correctly on their own.
Voltage or current input channel dead.
Current shunt or clamp input faults.
Harmonic measurement errors.
Power or energy computation inaccurate.
Cooling fan or thermal shutdown.
Internal power supply faults.
GPIB, LAN, USB or remote-control faults – which breaks automated test sequences while the instrument still works from the front panel.
Display, keypad or front-panel faults.

FAQs

What if it is not economical to repair? We tell you in the quote. The evaluation is free and there is no obligation to proceed.

Are harmonics verified as well as fundamentals? Yes. Harmonic accuracy is a separate specification and drifts independently.

Every repair carries a 90-day parts-and-labor warranty, with a firm quote before any work begins. Email us or submit a service request.
