Tektronix MSO71604C Oscilloscope Repair

$245.00

🛡️ 90-Day Warranty ✓ Fee Credited to Repair ⚡ No Forms Needed

Restore your Tektronix MSO71604C to factory specifications with June Company’s certified repair service. We restore full performance for FFT analysis and eye diagram functions.

Helpful Resources

📋 How It Works

Submit Request – Pay evaluation fee & provide equipment details
Ship to Us – Send your equipment to our Oregon facility
We Evaluate – Detailed diagnosis & repair estimate
Fee Credited – Your evaluation fee applies to repair cost
We Repair – Professional repair with 90-day warranty

🔧 Fast Turnaround: Most repairs are completed within 1–3 business days.
📏 Precision Calibration: NIST-traceable calibrations included for most repairs.
🛡️ Warranty: 90-day warranty on all repairs.
📝 Transparency: Detailed evaluation and repair estimate before work begins.

✓ Evaluation Fee Credited Toward Repair

This evaluation fee is applied as credit toward your final repair cost. After we evaluate your equipment, you'll receive a detailed estimate before any repair work begins.

Description

Tektronix MSO71604C Oscilloscope Repair

The Tektronix MSO71604C is a 16 GHz mixed-signal performance oscilloscope (MSO70000 series) — a 4 analog plus 16 digital channel scope for high-speed serial, signal-integrity, and mixed-signal design work. As a precision high-bandwidth acquisition instrument, its faults concentrate in the analog front-end, the ADC/acquisition board, the trigger, and the logic-acquisition hardware.

June Company repairs and calibrates the Tektronix MSO71604C for high-speed design and signal-integrity teams.

Common Tektronix MSO71604C problems we fix

FFT / analysis or acquisition faults — acquisition errors affecting FFT and analysis results, repaired and recalibrated.
Input-channel restoration — a dead, noisy, or inaccurate analog channel from front-end damage (often an overload), repaired and recalibrated.
Digital (MSO) channels not working — the logic-acquisition hardware, restored.
Trigger-system faults — unstable or wrong triggering, corrected.
Won’t boot or display faults — power/board or display, repaired.

FAQs

A channel reads wrong after an overload — fixable? Yes. Front-end damage is the most common scope fault and it’s repairable, then the channel is recalibrated so vertical accuracy and bandwidth are restored, with a NIST-traceable certificate.

Do you handle the digital channels? Yes — the logic-acquisition hardware is diagnosed and repaired.

Every repair includes NIST-traceable calibration and a 90-day parts-and-labor warranty. Email us or submit a service request.
