Siglent SDG800 Waveform Generator Repair

$245.00

🛡️ 90-Day Warranty ✓ Fee Credited to Repair ⚡ No Forms Needed

Restore your Siglent SDG800 to factory specifications with June Company’s certified repair service. Common issues include output connector wear and modulation circuit faults.

Helpful Resources

📋 How It Works

Submit Request – Pay evaluation fee & provide equipment details
Ship to Us – Send your equipment to our Oregon facility
We Evaluate – Detailed diagnosis & repair estimate
Fee Credited – Your evaluation fee applies to repair cost
We Repair – Professional repair with 90-day warranty

🔧 Fast Turnaround: Most repairs are completed within 1–3 business days.
📏 Precision Calibration: NIST-traceable calibrations included for most repairs.
🛡️ Warranty: 90-day warranty on all repairs.
📝 Transparency: Detailed evaluation and repair estimate before work begins.

✓ Evaluation Fee Credited Toward Repair

This evaluation fee is applied as credit toward your final repair cost. After we evaluate your equipment, you'll receive a detailed estimate before any repair work begins.

Description

Siglent SDG800 Waveform Generator Repair

The Siglent SDG800 Waveform Generator is a signal generator – it produces a signal of known frequency, level and modulation, which means its output attenuator and levelling loop carry the accuracy of everything it is used to test.

June Company’s certified technicians repair the Siglent SDG800 Waveform Generator for RF engineers, communications test teams, EMC laboratories, and manufacturing test departments. Every instrument is repaired at component level and verified against reference standards before it ships back, with the measured results documented.

Common Siglent SDG800 Waveform Generator problems we fix

Modulation not applying correctly.
Output attenuator relay faults.
Harmonic or spurious performance degraded.
Cooling fan or thermal shutdown.
Internal power supply faults.
GPIB, LAN, USB or remote-control faults – which breaks automated test sequences while the instrument still works from the front panel.
Display, keypad or front-panel faults.
Output level inaccurate or not levelling – the attenuator and levelling loop, which drift together and are verified across the full output range.
Frequency accuracy or reference drift.

FAQs

How long does a repair take? Most are completed in 5-10 business days, with a firm quote after evaluation and before any work begins.

Are the measurements verified after repair? Yes, against reference standards, with the measured results documented and returned with the instrument.

Every repair carries a 90-day parts-and-labor warranty, with a firm quote before any work begins. Email us or submit a service request.
